ABB - 2TLJ010026R0000 - RT6 24V DC Safety Relay, 3NO/1NC, 45 mm

The ABB 2TLJ010026R0000 (formerly Jokab Safety) RT6 is a versatile safety relay designed for monitoring safety devices such as emergency stops, light curtains, and interlocked gates. Operating on a 24 V DC supply, this relay features a compact 45 mm housing and offers multiple input configurations, including single or dual-channel inputs. It provides three normally open (NO) and one normally closed (NC) safety outputs, ensuring reliable performance in safety-critical applications.

Key Features:

• Model: RT6

• Brand: ABB (Jokab Safety)

• Part Number: 2TLJ010026R0000

• Supply Voltage: 24 V DC

• Housing Width: 45 mm

• Input Options: Single or dual-channel

• Reset Modes: Manual supervised or automatic

• Safety Outputs: 3 NO + 1 NC relay contacts

• Information Outputs: 2 voltage-free transistor outputs

• Mounting: DIN rail

• Applications: Suitable for emergency stops, light curtains, interlocked gates, safety mats, and other safety devices
