Endress+Hauser - PMP131-A1B01A1R - Cerabar T Pressure Transmitter 0–6 bar 4–20mA

The Endress+Hauser Cerabar T PMP131-A1B01A1R is a compact and reliable pressure transmitter designed for accurate measurement of gauge pressure in gases, vapors, and liquids. Featuring a piezoresistive sensor with a metallic measuring diaphragm, it offers a measuring range of 0 to 6 bar and provides a 4–20 mA analog output. Its robust construction and IP65-rated housing ensure durability in various industrial environments.

Key Features:

• Model: PMP131-A1B01A1R

• Brand: Endress+Hauser

• Series: Cerabar T

• Measuring Range: 0 to 6 bar (0 to 600 kPa)

• Output Signal: 4–20 mA analog

• Process Connection: G½ thread, flush-mounted, AISI 304 stainless steel

• Electrical Connection: ISO 4400 plug (M16), IP65/NEMA 4X

• Accuracy: ±0.5% of full scale

• Long-Term Stability: ±0.15% of URL per year

• Overpressure Limit: 24 bar

• Operating Temperature Range: –25 °C to +70 °C

• Power Supply: 12–30 V DC

• Approvals: ATEX, SIL, GL

• Applications: Suitable for measuring gauge pressure in gases, vapors, and liquids across various industrial processes.
