Baumer - BHG 16.24K10-B2-5 - Incremental Hollow Shaft Encoder, 1024 PPR

The Baumer BHG 16.24K10-B2-5 is a compact incremental rotary encoder designed for precise position and speed feedback in industrial automation systems. Featuring a 12 mm blind hollow shaft and delivering 1024 pulses per revolution (PPR), this encoder utilizes optical sensing technology to ensure high-resolution output. Its push-pull (HTL) output configuration provides compatibility with various control systems, making it suitable for a wide range of applications.

Key Features:

• Model: BHG 16.24K10-B2-5

• Brand: Baumer

• Encoder Type: Incremental rotary encoder

• Shaft Type: Blind hollow shaft

• Shaft Diameter: 12 mm

• Resolution: 1024 pulses per revolution (PPR)

• Output Signal: Push-Pull (HTL)

• Supply Voltage: 10–30 V DC

• Protection Rating: IP42

• Operating Temperature Range: -20°C to +85°C

• Housing Diameter: 58 mm

• Mounting: Clamping ring with torque support

• Connection: Cable output

• Applications: Ideal for use in automation systems, including motor feedback, conveyor systems, and positioning tasks
