Bosch Rexroth - R162222320 - Ball Runner Block, Size 25, High Accuracy

The Bosch Rexroth R162222320 is a high-precision ball runner block from the KWD-025-SNS-C2-H-1 series, designed for demanding linear motion applications. With a slimline width, standard height, and normal length, it is ideal for installations with limited transverse space. This runner block offers high load ratings in all four main directions, ensuring reliable performance in various industrial settings.

Key Features:

• Model: KWD-025-SNS-C2-H-1

• Part Number: R162222320

• Brand: Bosch Rexroth

• Runner Block Type: Ball runner block

• Size: 25

• Format: SNS (Slimline width, Normal length, Standard height)

• Material: Unalloyed carbon steel

• Accuracy Class: H (High)

• Preload Class: C2 (Medium preload)

• Ball Chain: Without

• Lubrication: Pre-lubricated with Dynalub 510

• Sealing: Integrated all-around sealing

• Mounting: Attachments can be mounted from above; end-face fastening thread for all attachments

• Dynamic Load Capacity (C): 28,600 N

• Static Load Capacity (C₀): 35,900 N

• Dynamic Torsional Moment Load Capacity (Mₜ): 410 Nm

• Static Torsional Moment Load Capacity (Mₜ₀): 510 Nm

• Dynamic Longitudinal Moment Load Capacity (Mₗ): 290 Nm

• Static Longitudinal Moment Load Capacity (Mₗ₀): 360 Nm

• Maximum Acceleration: 500 m/s²

• Maximum Speed: 5 m/s

• Operating Temperature Range: -10°C to +80°C

• Weight: 0.533 kg

• Applications: Ideal for applications requiring high precision and rigidity, such as CNC machinery, automation systems, and industrial equipment
