The IEI AFL‑057A‑LX/WT‑R/256MB is a rugged, fanless panel PC featuring a 5.7″ VGA resistive touchscreen, powered by an energy‑efficient AMD Geode LX‑800 CPU. It includes built-in 802.11 b/g wireless LAN, Bluetooth v2.0, dual USB ports, dual serial ports, CF card slot, and audio—ideal for industrial HMI, automation, point-of-sale, or outdoor control systems.

Key Features:

Model: AFL‑057A‑LX/WT‑R/256MB
Display: 5.7″ VGA TFT LCD, 640×480 resolution, 400 cd/m² brightness, 262K color, 50,000 h LED backlight
Touchscreen: 4‑wire resistive panel
Processor: AMD Geode LX‑800, 500 MHz
Memory: 256 MB DDR RAM onboard; expandable to 1 GB via SO‑DIMM slot
Storage: CompactFlash Type II slot; additional expansion via VGA/CF
Connectivity:

– 2× USB 2.0 ports

– 1× VGA output

– 1× 10/100 Mbps LAN

– 1× RS‑232; 1× RS‑232/422/485 (RJ‑45)

– Integrated WLAN 802.11 b/g and Bluetooth v2.0 w/ external antenna
Audio: Dual internal 1.5 W speakers; front panel power LED
Power Modes: Switchable AT/ATX mode; 12 V DC input; optional 9–30 V DC converter
Ruggedness & Mounting: Fanless die-cast aluminum back, ABS front; IP64 front bezel; VESA 75×75 mm mounting
Power Consumption: ~15 W typically; 12 V input via adapter supplied (90–264 VAC in)
Dimensions & Temperature: 180 × 135 × 55 mm; 0.8 kg; rated 0–50 °C (storage –20 °C to 60 °C)
Certifications: CE, FCC, CB, CCC; UL safety approved; RoHS compliant

IEI (AFL) – AFL-057A-LX/WT-R/256MB – 5.7″ Fanless Panel PC w/ AMD Geode LX-800
