The JUMO DICON 500 (model 703570/081-1100-555551-23-54/00) is a universal process controller designed for precise regulation of various physical parameters in industrial applications. It features two four-digit 7-segment displays, multiple LEDs for switch positions and operating modes, an 8-digit matrix display, and six keys for intuitive operation. The controller is suitable for managing temperature, pressure, and other process variables, offering flexibility and reliability in control systems.

Key Features:

• Dual 7-Segment Displays: Provides clear visualization of process values and setpoints.

• LED Indicators: Multiple LEDs indicate switch positions and operating modes for enhanced monitoring.

• Matrix Display: An 8-digit matrix display offers additional information and status updates.

• User-Friendly Interface: Equipped with six keys for straightforward parameter setting and navigation.

• Universal Application: Capable of controlling various physical parameters, including temperature and pressure.

Technical Specifications:

• Model Number: 703570/081-1100-555551-23-54/00

• Display: Two four-digit 7-segment displays and an 8-digit matrix display

• Inputs: Configurable for different sensor types (e.g., thermocouples, RTDs)

• Outputs: Configurable for various control outputs (e.g., relay, analog)

• Power Supply: [Information not specified]

• Dimensions: [Information not specified]

• Weight: [Information not specified]

Applications:

• Temperature Control: Ideal for precise temperature regulation in industrial processes.

• Pressure Management: Suitable for maintaining desired pressure levels in various systems.

• General Process Control: Versatile controller for managing multiple process variables in manufacturing and processing industries.

JUMO - 703570/081-1100-555551-23-54/00 - DICON 500 Universal Process Controller
