Schneider Electric – LMC402CAA10000 – PacDrive 3 Motion Controller, 16‑Axis

The Schneider Electric LMC402CAA10000 is a high-performance 16‑axis motion controller from the PacDrive 3 family. Designed for OEM and machine automation, it synchronizes up to 130 servo axes with 1 ms network update times, offering robust digital I/O, analog channels, and versatile communication interfaces—all in a compact IP20 module.

🔧 Key Features

• Model / MPN: LMC402CAA10000 – 16‑axis motion controller, basic acceleration kit

• Axes: Controls up to 16 servo axes; scalable to 130 axes with Sercos III

• Digital I/O: 20 inputs (±0–6 V / 20–33 V DC), 4 interrupt inputs, 16 probe inputs; 250 mA per output channel, leakage ≤0.4 mA

• Analog I/O: 2 analog inputs, ±10 V voltage, 0–20 mA current, 12‑bit resolution

• Power & Efficiency: 24 V DC supply; typical consumption 36 W; discrete output current 250 mA

• Communications: Dual Ethernet (Sercos III/fieldbus), CANopen, RS‑232/RS‑485, optional USB

• Performance: Up to 255 virtual axes, scalable motion architecture
