Main Features

Manufacturer: SDMO (a Kohler division)
Model/MPN: MICS TELYS 2
Device Type: Microprocessor-based digital control panel for generator sets, successor to original TELYS 1
Display & Controls:
- Large backlit screen with rotary-push navigation wheel
- Front panel buttons: Start, Stop, Menu, Escape, Emergency Stop
Communication Interfaces:
- USB Host and Device ports for parameter storage, firmware updates, and blind-load events log extraction
- RS-485 and Ethernet support—enables remote control via PC, mobile, or landline with no special software needed
- CAN bus interface for electronic motor control in modern gensets
Operating Modes & Measurements:
- Four operating modes: Manual, Automatic, Stop, Test
- Captures and logs up to 100 events including alarms and faults
- Integrated electrical parameters: voltage, current, power, energy counters (kW, kWh, kVAr, kVArh), power factor
Environmental & Protection Ratings:
- Operating temperature: –15 °C to +60 °C (storage –20 °C to +70 °C)
- Shock rating IK01; vibration compliant to IEC 68-2-6; salt spray resistance per EN 68011-2-11; humidity tolerance up to 95 % @ 45 °C
- Enclosure rating: IP‑30 front panel
Compliance & Standards:
- EMC: EN 61000‑6‑2 / 6‑4, EN 55011
- Low voltage: EN 60529; UL, CSA certifications
Status: Discontinued by SDMO; widely available through retrofit kits (APM403) and secondary markets

SDMO (Kohler) – TELYS 2 – MICS Telys 2 Digital Control Panel for Generator Sets
