SENECA – Z107E – Ethernet to RS232/RS485 Serial Converter, Virtual COM Port

🔧 Product Overview

The SENECA Z107E is a compact, industrial-grade Ethernet-to-serial converter designed to bridge Ethernet networks with RS232 or RS485 serial devices. It enables remote serial communication over TCP or UDP protocols and supports virtual COM port functionality, making it ideal for applications requiring seamless integration between modern Ethernet systems and legacy serial equipment.

📐 Key Specifications

• Power Supply: 12–40 V DC / 12–28 V AC, 50–60 Hz

• Power Consumption: 1.2 W

• Isolation Voltage: 500 V AC

• Serial Interfaces: RS232 and RS485

• Communication Protocols: TCP/IP and UDP

• Mounting: 35 mm DIN rail

• Protection Rating: IP20

• Operating Temperature Range: -20°C to +70°C

• Dimensions (W × H × D): 17.5 mm × 100 mm × 112 mm

• Status Indicators: Power supply, Ethernet link, Ethernet connection

• Country of Origin: Italy
