The SensoPart MFU 12 P4 (Order No. 968-61000) is a versatile SmartPlug designed to enhance sensor functionality in industrial automation systems. This multifunctional switching device allows for the conversion of PNP input signals to PNP or NPN outputs and offers programmable features via a USB interface. Its compact design facilitates easy integration between sensors and control systems, making it ideal for applications requiring signal adaptation and amplification.

Key Features:

Model: MFU 12 P4
Brand: SensoPart
Function: Multifunctional SmartPlug switching device
Input Type: PNP
Output Type: PNP/NPN (programmable)
Programming Interface: USB
Operating Voltage: 10–30 V DC
Maximum Output Current: 400 mA
Switching Frequency: Up to 10 kHz
Housing Material: Plastic PBTP/PA
Dimensions: Ø20 × 60 mm
Protection Class: IP67
Operating Temperature Range: 0 °C to +60 °C
Applications: Suitable for signal adaptation, amplification, and logic functions in industrial automation systems
