Yaskawa – CIMR‑LK4V0023FAA – V1000 Series 7.5 kW AC Drive (380–480 V)

The Yaskawa CIMR‑LK4V0023FAA is a V1000 series variable frequency drive, offering robust vector control for 7.5 kW (10 hp) three-phase motors. Designed for industrial and elevator applications, it supports 380–480 V input and delivers precise motor control with enhanced protection and effective braking. Ideal for retrofits, OEM equipment, or replacement of elevator/machine drives.

Key Features

• Model / MPN: CIMR‑LK4V0023FAA

• Series: V1000 (also referenced as L1000 in lift‑drive markets)

• Power Rating: 7.5 kW (10 hp) heavy-duty, 18 A @ 400 Hz; 10 hp nominal

• Voltage Input: 3-phase 380–480 V, 50/60 Hz

• Control Type: Flux vector open-loop; supports PM motors, safe torque‑off input, auto-tuning, and high‑flux braking

• Protection & Features: Overload, over/under-voltage, short-circuit, over-temperature, motor thermistor input, built-in EMC filter and braking function

• Enclosure: IP20 rated, vertical/horizontal mounting; compact design (approx. 140×200×180 mm)
