Schneider Electric – BSH1001P01A2A – Lexium Servo Motor, 2.7 N·m, 3 kW, 3 000rpm

The Schneider Electric BSH1001P01A2A is a robust AC synchronous servo motor from the Lexium series. With a 100 mm flange and 2.7 N·m rated torque, it delivers 1.3 kW at 3000 rpm (480 V, 3 phase). It features a smooth shaft, IP50 protection, and compatibility with SinCos single-turn feedback systems. Ideal for precise motion control in industrial automation applications.

Key Features & Specifications:

• Model: BSH1001P01A2A – Lexium 5 & Motoren series

• Type: AC synchronous servo motor (no brake) with smooth shaft

• Rated Torque: 2.7 N·m

• Output Power: 1.3 kW

• Speed: 3000 rpm, 8-pole configuration

• Voltage: 480 V, 3-phase AC

• Feedback: SinCos single-turn encoder (Hiperface compatible)

• Frame/Flange: 100 mm, untapped shaft

• Protection: IP50 housing

• Mounting: 4 M9 threaded holes; standard flange design

• Weight/Size: ~4.2 kg; 168.5 mm length; shaft Ø19 mm
