Schneider Electric – VW3A3327 – Profinet Communication Card (Altivar 61/71)
The Schneider Electric VW3A3327 is a Profinet communication card designed for use with Altivar 61 and Altivar 71 variable frequency drives. It enables 100 Mbps Ethernet connectivity over two RJ45 ports, featuring advanced Profinet services including Media Redundancy Protocol (MRP), real-time Ethernet (RT), PROFIdrive profiles, embedded web server, FTP access, drive monitoring, and parameter configuration functionalities. Ideal for industrial automation networks requiring fast, reliable communication and system integration.
Key Features:
Model / MPN: VW3A3327 (Schneider Electric)
Compatible Drives: Altivar 61 and Altivar 71 series
Communication Protocol: Profinet with MRP support; Ethernet, TCP/UDP, LLC & MAC full-duplex
Network Ports: Dual RJ45 connectors supporting 100 Mbps full duplex
Industrial Services: Embedded web server, drive recorder, FTP, Ethernet/IP setup, data editing, multi-language UI, FDR agent, save/restore parameters, drive monitoring and statistics
LED Status Indicators: Link, module status, network status, TX/RX for each port
Weight: ~0.29 kg (0.63 lb)
RoHS Compliance: EU RoHS and China RoHS confirmed
