1PCs Telemecanique – XS7J1A1DAL2 – Flat 8 × 22 × 8 mm Inductive Sensor, 2m

The XS7J1A1DAL2 from Telemecanique (OsiSense XS series) is a compact, flat-form inductive proximity sensor with a 2.5 mm detection range. Designed for embedded mounting in tight industrial spaces, it features a 2 m pre-wired cable and is crafted for reliable automation in conveyors, packaging, and robotics.

Key Features:

• Model / P/N: XS7J1A1DAL2

• Sensor Type: Inductive, flush-mountable, 2-wire normally open (NO) output

• Body Dimensions: 8 × 22 × 8 mm; PBT housing

• Sensing Range (Sn): 2.5 mm

• Operating Voltage: 12–24 V DC (10–36 V DC), with reverse polarity protection

• Output Current: 1.5–100 mA with short-circuit/overload protection

• Response Frequency: ≤ 4000 Hz

• Protection & Durability: IP67-rated; vibration-resistant up to 25 g; shock 50 g (IEC 60068)

• Operating Temp: –25 °C to +70 °C; storage –40 °C to +85 °C

• Cable: 2 m PVC, Ø 5.4 mm; unshielded two-wire lead

• LED Indicator: Yellow LED for output state

• Certifications: CE, UL, CSA, C‑Tick; Carson RoHS-compliant, Prop‑65 notice
