ABB – 1SAR600120R0006 – R600 Series Interface Relay Module, 1 SPDT, 24 V DC Coil

The ABB 1SAR600120R0006 is an R600 Series interface relay module featuring a single-pole double-throw (1 SPDT) contact and a 24 V DC coil. Designed for industrial automation and control applications, this relay provides reliable electrical isolation, signal amplification, and switching between control systems and field devices. The module is DIN rail mountable and includes a green LED status indicator for coil activation. It supports a wide range of switching voltages and currents, making it suitable for interfacing PLCs, sensors, and actuators in control panels.

Key Features:

• Coil voltage: 24 V DC

• Contact configuration: 1 SPDT (single-pole double-throw)

• Switching capacity: Up to 6 A (AC12/DC12), 3 A (AC15/DC13)

• Switching voltage range: 6–250 V AC / 6–220 V DC

• Status indication: Green LED for coil status

• Mounting: DIN rail

• Contact material: Silver alloy

• Wire size: 0.2–2.5 mm² (24–12 AWG)

• Ambient temperature range: –40°C to +55°C (operating)

• Protection rating: IP20

• Approvals: UL, CSA, CE, and others for global use
