Eaton Vickers – DGMPC-3-ABM-41 – ISO 4401-03 Pilot-Operated Check Valve

The Eaton Vickers DGMPC‑3‑ABM‑41 is a durable pilot-operated check valve from the System Stak™ series. Engineered for ISO 4401-03 subplate mounting, it provides secure locking of both A and B actuator ports until released by pilot pressure. With high-pressure handling and robust construction, this valve is ideal for industrial and mobile hydraulic systems requiring reliable load holding.

Key Features:

• Model: DGMPC‑3‑ABM‑41 (also referenced as 02‑139088)

• Function: Pilot-operated dual check valve—locks lines A & B until pilot pressure is applied

• Flow Rate: Up to 60 L/min (16 US gpm)

• Pressure Rating: Maximum 315 bar (4,500 psi)

• Cracking Pressure: Approx. 1 bar (14 psi)

• Mounting Interface: ISO 4401‑03 (D05) subplate/manifold mounted

• Materials: Cast iron body with Buna‑N seals

• Operating Temperature: –20 °C to +80 °C (–4 °F to +176 °F)

• Dimensions: ~101 mm L × 40 mm W × 40 mm H; weight ~0.8 kg
