ERSCE - E100-00-EI - Compact Limit Switch, Side Rotary Lever, 1NO/1NC, IP66

The ERSCE E100-00-EI is a compact limit switch designed for precise position detection in industrial automation systems. Featuring a side rotary lever actuator and snap-action contacts, this switch ensures reliable performance in various applications.

Key Features:

• Model: E100-00-EI

• Brand: ERSCE

• Switch Type: Limit Switch

• Actuator Type: Side rotary lever

• Contact Configuration: 1 NO + 1 NC (snap-action)

• Housing Material: Thermoplastic body with metal head

• Protection Rating: IP66

• Electrical Ratings:

  • Rated Insulation Voltage (Ui): 500 V AC

  • Rated Thermal Current (Ithe): 10 A

  • Rated Operational Current (Ie):

    • 6 A at 230 V AC (AC-15)

    • 3 A at 400 V AC (AC-15)

• Mechanical Durability: >10 million operations

• Electrical Durability: >1 million operations

• Ambient Temperature Range: -25°C to +70°C

• Mounting: Surface mount with two fixing holes (per EN50047)

• Cable Entry: Pg 13.5

• Standards Compliance: IEC/EN 60947-5-1, UL (E72861), CSA (026716-0-000)

• Applications: Ideal for position detection in machinery, conveyors, and automation systems
