General Electric – MCRA031AT – C‑2000™ Mini Control Relay, 3 NO + 1 NC, 110‑120

The MCRA031AT is a 4-pole mini control relay from General Electric’s C‑2000™ (formerly GE, now ABB) series. Featuring a 3 normally-open + 1 normally-closed contact configuration and a 110–120 VAC coil, this compact relay supports DIN-rail or panel mounting—perfect for control circuits, interlocks, and PLC applications.

Key Features:

• Manufacturer: General Electric (C‑2000™ series)

• Model / P/N: MCRA031AT

• Contact Configuration: 3 NO + 1 NC (3 normally open + 1 normally closed)

• Coil Voltage: 110–120 VAC, 50/60 Hz (suffix AT)

• Contact Rating: Up to 10 A; suitable for both AC and DC applications

• Terminals: Standard screw-clamp; quick-connect Faston variants available

• Mounting: Clips onto 35 mm DIN rail or panel mounted via screws; 6 oz (170 g) weight

• Coil Wattage: Low-power design—efficient for PLC/automation control energy budgets

• Certifications: UL listed, CSA certified, CE compliant; meets IEC 60947‑1/4 standards
