The IFM PV7004 is a robust pressure switch designed for monitoring and controlling pressure in industrial applications. Key features include:

• Measuring Range: -1 to 10 bar (-14.5 to 145 psi), suitable for both vacuum and positive pressure applications.

• Process Connection: G1/4 external thread (DIN EN ISO 1179-2), compatible with standard industrial fittings.

• Outputs: Two programmable switching outputs, configurable as normally open or normally closed, with a maximum switching current of 100 mA.

• Operating Voltage: 18 to 30 V DC, accommodating common industrial power supplies.

• Accuracy: Switch point accuracy of < ±0.5% of the span, ensuring precise pressure monitoring.

• Temperature Range: Operational within -40°C to +90°C (-40°F to +194°F), ensuring reliability in diverse environmental conditions.

• Protection Rating: IP67/IP69K, offering high resistance to dust and water ingress, suitable for harsh industrial environments.

• Communication Interface: Equipped with IO-Link for seamless integration into advanced automation systems, enabling remote parameterization and diagnostics.

• Housing Material: Constructed with durable stainless steel (1.4542 / 17-4 PH) for wetted parts, ensuring compatibility with various media and longevity in industrial applications.

IFM - PV7004 - PV-010-REG14-UFRVG/US - Pressure Switch with IO-Link
