Micro Detectors – FARB/BP‑2E – 90° Polarised Diffuse Photoelectric Sensor

The Micro Detectors FARB/BP-2E is a 90° polarised diffuse photoelectric sensor designed for reliable object detection in industrial automation applications. It features a compact housing with M12 connector, and selectable PNP output with both normally-open and normally-closed contacts via a 2 m cable, providing flexible installation options.

Key Features:

• Model: FARB/BP‑2E

• Sensor Type: 90° polarised diffuse photoelectric detection (polarised to reduce false triggers)

• Housing & Connector: M12 plastic housing with 2 m radial cable output

• Supply Voltage: 10–30 V DC

• Current Consumption: ≤ 30 mA

• Output Type: PNP, both NO + NC contacts, ≤ 100 mA

• Leakage Current: ≤ 10 μA

• Voltage Drop (Output): ≤ 2 V @ 100 mA
