NIMAK – R414002965 – ED05 Proportional Pressure Control Valve, 11 bar, 1000 L/mi

The NIMAK R414002965 is a direct-acting proportional pressure control valve from the ED05 series, used in advanced pneumatic control systems. It precisely regulates output pressure based on analog control signals, offering up to 11 bar of pressure and a high nominal flow rate of 1000 L/min. Designed with a 5-pin M12 connector and an IP65 enclosure, it is suitable for demanding industrial automation environments.

Key Features & Specifications:

• Model / MPN: R414002965

• Series: ED05

• Type: Proportional pressure control valve

• Max Pressure: 11 bar

• Nominal Flow: 1000 L/min

• Control Input: 0–10 V or 4–20 mA

• Electrical Connection: 5-pin M12 connector

• Mounting Flexibility: α and β angles 0–90°

• Protection Rating: IP65

• Operating Temperature: 0 °C to +70 °C

• Medium: Compressed air (filtered, lubricated or non-lubricated)
