SDMO (Kohler) – TELYS 2 – MICS Telys 2 Digital Control Panel for Generator Sets

Main Features

• Manufacturer: SDMO (a Kohler division)

• Model/MPN: MICS TELYS 2

• Device Type: Microprocessor-based digital control panel for generator sets, successor to original TELYS 1

• Display & Controls:

  • Large backlit screen with rotary-push navigation wheel

  • Front panel buttons: Start, Stop, Menu, Escape, Emergency Stop

• Communication Interfaces:

  • USB Host and Device ports for parameter storage, firmware updates, and blind-load events log extraction

  • RS-485 and Ethernet support—enables remote control via PC, mobile, or landline with no special software needed

  • CAN bus interface for electronic motor control in modern gensets

• Operating Modes & Measurements:

  • Four operating modes: Manual, Automatic, Stop, Test

  • Captures and logs up to 100 events including alarms and faults

  • Integrated electrical parameters: voltage, current, power, energy counters (kW, kWh, kVAr, kVArh), power factor

• Environmental & Protection Ratings:

  • Operating temperature: –15 °C to +60 °C (storage –20 °C to +70 °C)

  • Shock rating IK01; vibration compliant to IEC 68-2-6; salt spray resistance per EN 68011-2-11; humidity tolerance up to 95 % @ 45 °C

  • Enclosure rating: IP‑30 front panel

• Compliance & Standards:

  • EMC: EN 61000‑6‑2 / 6‑4, EN 55011

  • Low voltage: EN 60529; UL, CSA certifications

• Status: Discontinued by SDMO; widely available through retrofit kits (APM403) and secondary markets
