SICK - WT2S-F211 - Miniature Photoelectric Sensor, Background Suppression, 15mm

The SICK WT2S-F211 is a compact photoelectric proximity sensor featuring background suppression, designed for precise object detection in constrained industrial environments. Its PinPoint LED technology ensures a focused light spot for accurate detection, while the robust ABS housing and IP67/IP69K ratings provide durability in harsh conditions.

Key Features:

• Model: WT2S-F211

• Brand: SICK

• Part Number: 1024171

• Sensor Type: Photoelectric proximity sensor with background suppression

• Sensing Range: 1 mm to 15 mm

• Light Source: Visible red light (660 nm) using PinPoint LED

• Light Spot Size: Ø 1.5 mm at 7 mm distance

• Output Type: PNP, dark switching

• Switching Frequency: 800 Hz

• Response Time: < 0.6 ms

• Supply Voltage: 10–30 V DC

• Output Current: ≤ 50 mA

• Connection: 200 mm PVC cable with M8, 3-pin connector

• Housing Material: ABS plastic

• Optics Material: PMMA

• Protection Class: IP67 and IP69K

• Operating Temperature Range: –20 °C to +50 °C

• Dimensions (W × H × D): 7.6 mm × 25.1 mm × 12.5 mm

• Weight: Approximately 20 g

• Certifications: CE

• Applications: Ideal for precise object detection in packaging machines, assembly lines, and other automation systems where space is limited.
