Swagelok - 6LVV-DPHFR4-P-CM-2 - UHP Diaphragm Valve, 1/4” Female VCR, Manual
The Swagelok 6LVV-DPHFR4-P-CM-2 is an ultrahigh-purity (UHP) high-pressure diaphragm-sealed valve designed for critical gas delivery systems. Constructed from 316L VIM-VAR stainless steel and cleaned to SC-01 specifications, this valve features a manual directional handle and an integrated indicator switch for remote position monitoring. Its robust design and precise engineering make it ideal for semiconductor manufacturing, pharmaceutical processing, and other applications requiring stringent purity standards.
Key Features:
Model: 6LVV-DPHFR4-P-CM-2
Brand: Swagelok
Valve Type: Ultrahigh-Purity High-Pressure Diaphragm-Sealed Valve
Body Material: 316L VIM-VAR Stainless Steel
End Connections: 1/4” Female VCR® Face Seal (Metal Gasket)
Flow Pattern: Straight (2-way)
Handle Type: Manual Directional Handle (White)
Seat Material: PCTFE
Cleaning Process: Ultrahigh-Purity Process Specification (SC-01)
Surface Finish: 5 µin (0.13 µm) Ra
Cv (Flow Coefficient): 0.2
Operating Temperature Range: -10°C to +65°C
Maximum Operating Pressure: 3045 psig @ 70°F (209 bar @ 20°C)
Indicator Switch: Integrated for remote open/closed position monitoring
Applications: Ideal for UHP gas systems in semiconductor fabrication, pharmaceutical manufacturing, and other high-purity environments
